Easy Pilot Access integrates UAV mission planning,payload control, LiDAR data capture, and real-timemonitoring into one field workflow. Designed forDJI M300/M350/M400 platforms, it supportsDEM-based terrain following, RTK positioning, andreal-time point cloud preview for efficient UAVLiDAR operations.
DEM-Based Terrain Following
High-Accuracy RTK Positioning
Real-Time Point Cloud Preview
Dual Control Options
EPiCloud Center is professional UAV LiDAR processing software for GNSS/INS processing, strip adjustment, quality validation, and standard point cloud export. It provides a streamlined workflow that transforms raw UAV LiDAR data into accurate and reliable point cloud deliverables.
GNSS/INS Trajectory Processing
Point Cloud Generation & Refinement
Data Quality Assessment
Industry-Standard Data Export
| Model | X10 | X10 Plus |
| Weight① | 1280g | |
| Dimensions | 159mm × 118mm × 127mm | |
| Power Consumption | Typ. 25W | Typ. 26W |
| Power Supply | 10~30V DC | |
| Device Interface | DJI Skyport/Other Interface Available Upon Request | |
| Data Storage | USB Flash Drive 256 GB | |
| Operating Temperature | -10℃ ~ 50℃ | |
| Storage Temperature | -20℃ ~ 60℃ | |
| System Accuracy | 5cm | |
| Compatible Platform | DJI M300/M350/M400/Other UAV Models | |
| Scan Principle | ToF | |
| Laser Class | Class I | |
| Wavelength | 905nm | |
| Range | 0.05~120 m | |
| Horizontal FoV | 360° | |
| Vertical FoV | 30°（-15°~ +15°） | 31°（-16°~ +15°） |
| Data Points | Single Return : 320,000pts/s Dual Return : 640,000pts/s | Single Return : 640,000pts/s Dual Return : 1,280,000pts/s |
| GNSS Signal Tracking | GPS,BDS,GLONASS,GALILEO | |
| Positioning Accuracy(post-processing) | Horizontal:1cm / Vertical:2cm | |
| Position Data Rate | ≥10Hz | |
| Attitude Accuracy(post-processing) | Heading:0.05° / Pitch/Roll:0.01° | |
| Attitude Data Rate | ≥100Hz | |
| Resolution of Panoramic Image | Approx. 26MP | |
| Dimensions | 23.5mm × 15.7mm | |
| FoV② | 73° | |
| GSD | 2.3cm@100m AGL | |
| Weight | 1051g（Battery not Included） | |
| Dimensions | 136mm × 149mm × 108mm | |
| Scanning Mode | Fix Installed | |
| Battery Duration | 4h for Single Battery | |
| Accuracy | Relative Accuracy 2cm/Absolute Accuracy 5cm | |
| Resolution of Panoramic Image | Approx. 17MP | |
